- Robust Metallic Construction
- Suitable for continuous unsupervised operation
- Designed for synchronous heating and stirring
- The magnetic coil motorless technology provides noiseless and consistent stirring on all positions
- Homogeneous temperature distribution across the heating plate
- Hot top warning indication
- Timer function
- Adjustable reverse operation for stirring
- Stirring speed remains constant, even when load changes
- SPC-mode for a low self-warming of the surface
- Multiple opening modes selection
- Error codes display
- Continuous stir modes possible
- Can be operated with Labs-connect App over Wifi/USB Controls
Technical Specification:
| Set-up plate material | : Aluminium |
| Number of stirring positions | : 15 |
| Stirring position distance | : 90mm |
| Speed Range | : 0 – 1000 rpm |
| Speed Control | : 10 RPM Steps |
| Stirring quantity max.H2O | : 6L (400ml x 15) |
| Silicon Mat | : Yes |
| Stirring bar length max. | : 30mm x 8mm |
| Heating temperature range | : Room temp. – 120°C |
| Control display | : LED |
| Input Type | : Key Button |
| Adjustable safety circuit min. | : 50°C |
| Adjustable safety circuit max. | : 130°C |
| Timer range | : 00:01 to 99:59 [Hour: Minute] |
| Set-up plate dimensions | : 274x504mm |
| Dimensions (W x H x D) | : 281x81x609mm |
| Weight | : 10.6 KG (approx) |
| Permissible ambient temperature | : 5 – 40°C |
| Permissible relative humidity | : 80% |
| Protection class according to DIN EN 60529 | : IP40 |
| Also Known as | : 415.DG.01, 415.DG.02 |
Included Accessory:
| Cat. No. | Accessories |
|---|---|
| 1500.150.02 | (15) Magnetic Stirring bar 30 mm x 8 mm |
