Labs-Connect™ Technology

  • Robust Metallic Construction
  • Designed for synchronous heating and stirring
  • Suitable for continuous unsupervised operation
  • Silicone mat for anti-skid.
  • The magnetic coil motorless technology provides noiseless and consistent stirring on all positions
  • Homogeneous temperature distribution across the heating plate
  • Hot top warning indication
  • Timer function
  • Multiple modes with mode selection key
  • Constant stirring speeds even with viscosity changes
  • SPC-mode for a low self-warming of the surface
  • Error codes display


Technical Specification:

Set-up plate material: Aluminium
Number of stirring positions: 5
Stirring position distance: 90mm
Speed Range
: 0 – 1000 rpm
Stirring quantity max. per stirring position (H2O): 2L
Silicone Mat: Yes
Stirring bar length max.: 30mm x 8mm
Heating temperature range: Room temp. – 120°C
Input Type: Key Button
Set-up plate dimensions: 514x122mm
Dimensions (W x H x D): 600x120x80mm
Weight: 4.5 (Approx.)
Permissible ambient
temperature		: 5 – 40°C
Permissible relative humidity: 80%
Protection class according to DIN EN 60529: IP40
Speed control: 10 RPM Steps
Control display: LED
Adjustable safety circuit min.: 50°C
Adjustable safety circuit max.: 130°C
Timer range: 00:01 to 99:59 [HH: MM]
Also Known as: 411.DG.01
Temp ControlRPMHeat & StirChoice
upto 120° C0-1200 RPMSetup6 Mode
