- PU coated aluminium alloy body construction ensures durability
- Interchangeable aluminum alloy sample blocks provide versatility and allow for easy cleaning and disinfecting
- Precise temperature control with PID circuit
- Digital controls and display of time and temperature
- Built-in temperature sensing probe for outstanding temperature accuracy and control
- Timer allows the user to accurately monitor the heating time
Technical Specification :
| Single block heater | Double block heater | |
|---|---|---|
| Number of blocks | 1 | 2 |
| Heat output | 170 | 340 |
| Heating temperature range [°C] | 120°C | 120°C |
| Temperature display | YES | YES |
| Adjustment & display resolution [K] | 1 | 1 |
| Connection for ext. temp sensor | DIN | DIN |
| Temperature sensor | Pt1000 | Pt1000 |
| Set-up plate material | Aluminium alloy | Aluminium alloy |
| Set-up plate dimensions [mm] | 95*76*51 | 95*76*51 (2 block) |
| Fixed safety circuit [°C] | 130 | 130 |
| Timer | YES | YES |
| Time setting range [min] | 1 – 5999 | 1 – 5999 |
| Counter | YES | YES |
| Counter setting range [min] | 1 – 5999 | 1 – 5999 |
| Dimensions (W x H x D) [mm] | 160*80*271 | 163*106*332 |
| Weight [kg] | 2.8 kg (Approx.) | 5.2 kg |
| Permissible ambient temp[°C] | 5°C – 40°C | 5°C – 40°C |
| Permissible relative humidity [%] | 80 | 80 |
| Protection class according to DIN EN 60529 | IP 21 | IP 21 |
| Voltage [V] | 220 – 240V | 220 – 240V |
| Frequency [Hz] | 50/60Hz | 50/60Hz |
| Power input [W] | 170W | 340W |
