Safety Features

  • Microprocessor LCD Controller
  • Digital display for air flow rate
  • Transparent Front Door
  • Gauges Pressure (Statics Pressure Mano-Mater)
  • Magnahelic Gauge (for filter pressure)
  • U. V. Germicidal Tube in work area
  • Electronic Filter choke alarm
  • Spare HEPA Filters
  • Auto switch on/off for U.V. Germicidal tube & fluorescent light
  • Hour Meter for UV light with Test Certificate

Technical Specification :

Size:4’x2’x2ʼ
Size of Hepa:4’x2’x6:-ʼ
No. of Hepa:1 Nos
Cleaness:Class 100
Velocity:90 FPM +/-20
Hepa Filter:99.99% For particles >0.3 μm
PrefIlter:85 %efficiency for particles >0.5 μm (Washable)
Particle Count:Better than US Fed Std 209B Class10 and VDI 2083 Class 3
Cabinet:Laminated High Quality Wooden Board /PCRC Sheet Powder Coated/Stainless Steel SS 304(optional 316 grade)
Work Table:304 Stainless Steel (optional 316 grade
Airflow Speed:Control Speed Controller (Three Step Speed Controller)
Blower:High efficient centrifugal type with lifetime light
Light:High intensity, low wattage >800 luxlubricated bearings
Noise Level:55 dBA
Standard Accessories:Air/gas cock and mains power socket (16A)
Power Supply :220-230 V, 50 Hz.
