• PU Coated Aluminium Alloy Moulded Construction
  • Easy temperature & Stir controls
  • Installed with Safety PT sensor for fail safe operation.
  • Hot top indicator for temperatures above 50°C.
  • Large top plate to assist beakers upto 2000 ml.
  • High magnetic strength.
  • Electronic variable speed control with Knob for display.
  • Knob for regulating variable temperature.
  • Heat reach Indicator, To ensure you correct temperature of plate surface.
  • Stirring & temperature indicator
  • Error indicators for heat & Stir function inbuilt trouble shoot

Technical Specification :

Heating Mantle Material Stainless Steel 304 Grade with Ceramic Coating/Aluminum Alloy with Ceramic Coating
Dimension of heating plate Ø145 (For 610DNDG) | Ø150 (For 710DNAG)
Speed range 50-1600 RPM
Maximum stirring bar Length Can use up to 80 mm bar
(at lower speed)
Temperature Range Ambient to 350°C approx
Dimensions of hot plate body 273x160x102mm
Weight of body 3.0 kgs
Permissible ambient Temperature 5 – 40°C
Permissible relative moisture 80%
Weight of Capacity 20 Ltr
IP Class 22
