Safety Features
- Auto cut off of heater, when the water supply to the condenser is unavailable.
- Auto cut off of power to the Heater and condenser valve, on collection of sufficient distilled water in the tank.
- Water level monitoring window.
- Over voltage Circuit breaker protection.
- Complete shutdown of system on achieving the set water level in the distilled water container.
- Auto switching ON of the system when the water level is below the set level.
- Easy and safe dismantling of steam generator and water condenser for cleaning and removing of scale formation.
- Space saving, compact and user friendly.
Technical Specification:
| Steam Generator Dual | High-grade SS Steam Generator |
| Water condenser Dual | High-grade SS Water condenser |
| Housing material of construction | MS with powder-coated finish |
| Water level monitoring & control | Photoelectric sensor |
| Rate of Distillation | 1.5 lit/Hour double distillation |
| Heater | Dual Immersion Heater |
| Heater wattage | 2500 W each |
| Distilled water collection tank | Dual PVC Collection tank |
| Distilled water tank capacity | 5 lit |
| Membrane keypad with indications | 4.3” Touch with membrane keyboard |
| Electrical Requirement | 230V/50 Hz/single phase |
